Avalanche Photodiodes

OptoGration exploits the non-local behavior of impact ionization to provide low noise APDs sensitive to wavelengths ranging from less than 900 nm to 1700 nm. These APDs are available as discrete die with active apertures from 20 to 350 microns, as well as, highly uniform custom arrays with pixel pitches of as low as 10 microns. contact us for more info.


* Discrete APDs Available *
Part Number
Bandwidth (GHz, m=10)
Aperature (microns)
Responsivity (A/W, m=1)
OG-A-020-10
6.5
20 microns
0.63
OG-A-026-10
6.0
26 microns
0.63
OG-A-050-25
3.5
50 microns
0.94
OG-A-080-25
2.5
80 microns
0.94
OG-A-100-25
2.5
100 microns
0.94
OG-A-200-25
1.5
200 microns
0.94
OG-A-350-25
0.6
350 microns
0.94
